1. Getting Started#

What is DarSIA?#

DarSIA (“Darcy scale image analysis”) is a Python toolbox for turning photographs of a lab experiment into quantitative scientific data. It is widely used on FluidFlower experiments: time-lapse photos of a transparent rig filled with sand, where CO₂ is injected and its migration is tracked from color changes in the images.

Concretely, DarSIA takes a folder of JPEGs plus a small amount of metadata (the rig’s physical dimensions, where the sand layers are, a color calibration) and turns each image into physical quantities: CO₂ concentration, mass, saturation. The GUI is a Qt application that wraps this pipeline so you never have to write a driver script — you fill in a config file and click buttons.

Installing#

DarSIA is not on PyPI yet; install it from a clone (Python 3.12+).

git clone https://github.com/pmgbergen/darsia.git
cd darsia
uv sync --extra dev

The GUI needs the Qt bindings (PySide6), which are a normal dependency and are pulled in by the command above. If GUI imports fail with ModuleNotFoundError: PySide6, re-run uv sync --extra dev from the repo root. pip install -e ".[dev]" works too.

Launching the GUI#

uv run python -m darsia.gui

You should see an empty window like this:

Blank DarSIA window on first launch

A tour of the main window#

  • Sidebar (left) — six categories: Setup, Calibration, Analysis, Helper, Comparison, Utils. Each expands into concrete steps (e.g. Setup → Rig, Protocols, Depth, Facies). Clicking a step opens the matching settings form on the right and marks it as the “selected workflow.”

  • Settings panel (right) — a form built automatically from your config file. Fields are grouped into tabs (Rig, Corrections, Color Registry, …) that mirror the TOML sections in Core Concepts.

  • Toolbar, left to right: New config, Open config, Save config, Open Full Config (shows every section, not just the ones relevant to the selected step), Run ▶ / Stop ■ the selected workflow, Streaming Preview toggle, Logging toggle.

  • File menu also has Ctrl+O (Open Config), Ctrl+S (Save Config), Ctrl+N (New Config), and recently-opened files under Open Recent.

  • Run menu: Ctrl+Enter runs the currently selected sidebar step; Ctrl+Esc stops it.

  • Logging dock (bottom) shows what the app is doing; keep it open while you learn the tool. Streaming Preview (right dock, Ctrl+P) shows a live image of the current analysis step while a workflow runs.

Nothing is loaded yet because no config file has been opened. That is the subject of the next chapter.

The five-phase mental model#

Every DarSIA workflow project moves through the same five phases, and the sidebar categories map onto them one-to-one:

  1. Setup — one-time, per-experiment preparation: rig geometry, depth map, sand-layer segmentation (“facies”), imaging/injection protocol files, and the geometric (curvature) correction.

  2. Calibration — turn raw pixel colors into physical quantities: a color embedding (“color path”) calibrated against known reference images, then a color-to-mass calibration for CO₂.

  3. Analysis — the actual batch processing: cropping, mass/volume/ concentration maps, segmentation contours, finger detection, thresholding.

  4. Helper — interactive inspection tools (ROI picker, ROI viewer, color histograms, result viewer) that don’t produce pipeline output themselves, but help you choose good settings for the other phases.

  5. Comparison — after Analysis has run (possibly for several experiments), compare event timings or compute Wasserstein distances between runs.

You do these once, top to bottom, per experiment; Setup and Calibration are rarely revisited, Analysis is where you iterate.

Continue to the Quickstart walkthrough, which runs through all five phases using a real config file.
